Whirlpool Inverters
Elantra H-UPS
Whirlpool is the most recognized brand in home appliance globally. Our world clas products are engineered to suit the requirements of 'smart, confident and in-control' homemaker who knows what she wants. The product range is designed in a way that it employs unique technology and offers consumer relevant solutions. In addition to its existing product range, Whirlpool now comes up with new addition in the range of power accessories"Elantra" H-UPS. This H-UPS comes with a two year warranty, with Elantra you get the advantage of a host of features, international quality and anexciting range to suit your needs.
THE WHIRLPOOL "RANGE OF BENEFITS"
Elantra H-UPS uses 6th Sense Technology that use Auto Sense Intelligent Control.Which gives maximum power and backup time. This technology monitors the output level and battery voltage and adjusts the amplitude and wave shape of the sine wave and also corrects the Power Factor while battery charging.
- Auto Reset
- Protection Circuit
- Automatic Boost Charging Voltage Cutoff
- Automatic Battery Level Management
- Over Current Cutout
- No Humming Noise
Load Chart
Appliances | 600 VA Perfect for 1-2 bedroom house | 800 VA Perfect for 2-3 bedroom house | 1400VA Perfect for 3-4 bedroom house |
A B | A B | A B | |
FAN | 4 3 | 2 4 | 6 7 |
TUBE LIGHT | 3 3 | 2 4 | 6 7 |
TV | 0 1 | 1 1 | 1 1 |
COMPUTER | 0 1 | 1 0 | 1 0 |
Specifications
OUTPUT POWER | 600/800VA | 1400VA |
BATTERY VOLTAGE | 12V | 24V |
OUTPUT VOLTAGE AT NO LOAD | 220+/-7V | 220+/-7V |
OUTPUT FREQUENCY | 50HZ+/-0.5HZ | 50HZ+/-0.5HZ |
OUTPUT WAVEFORM | SINEWAVE | SINEWAVE |
LOW BATTERY CUT OFF | 10.5+/-0.2V | 20.5+/-0.2V |
BOOST CHARGING VOLTAGE | 14.2+/-0.2V | 28.4+/-0.2V |
TRICKLE CHARGING VOLTAGE | 14.2+/-0.2V | 28.4+/-0.2V |
CHARGING TECHNIQUES | AUTOMATIC BATTERY LEVEL MANAGMENT |
